Carbon Steel Wire Buckle Gate Valve

This carbon steel wire buckle gate valve from Shengshi Huagong is a shut-off valve suitable for various media conveying pipeline systems, and is widely used in industries, construction, water supply and drainage, etc. The valve is made of carbon steel as the main material. Carbon steel has high strength and good comprehensive mechanical properties, can withstand certain pressure and harsh working environment, and ensure long-term stable operation of the valve.

Send Inquiry

Product Description

The threaded connection of our carbon steel threaded gate valve is its remarkable feature. This connection method is easy to install and disassemble. It does not require complicated welding or flange connection tools. Only simple hand tools are needed to complete the connection with the pipeline. It is particularly suitable for small and medium-caliber pipeline systems and occasions with limited space or frequent installation and disassembly.

The carbon steel threaded gate valve realizes the on-off control of the fluid through the lifting and lowering movement of the gate plate. It plays a key switch role in the pipeline system to ensure the safety and stability of medium transportation.

Technical parameters

Project	Parameter range
Nominal diameter	DN15 - DN100
Nominal pressure	PN1.0MPa - PN2.5MPa
Applicable temperature	-20℃ - 350℃ (depending on the specific working conditions and materials)
Applicable media	Water, steam, air, oil, etc.
Valve body / valve cover material	Q235, 20# steel and other carbon steel
Gate material	Carbon steel
Valve stem material	45# steel, 35CrMo and other carbon steel or alloy steel
Sealing form	Hard seal
Connection method	Threaded connection
Drive mode	Manual
Standards	Follow GB (national standards), ISO (international standards), etc.
