Cast Iron Rising Stem Flange Gate Valve

The cast iron rising stem flange gate valve produced by our Tanggu Shengshi Huagong is a commonly used shut-off valve in industrial and civil pipeline systems. It is mainly used to control the flow of fluids to ensure stable and safe operation of the pipeline system.

Send Inquiry

Product Description

The cast iron rising stem flange gate valve is made of ductile iron as the main material. Ductile iron has high strength, high toughness and good casting performance. It can withstand high pressure and harsh working environment, laying a solid foundation for the long-term reliable operation of the valve. The rising stem design is its remarkable feature. During operation, the valve stem will move up and down with the rise and fall of the gate. The operator can quickly and accurately judge the opening and closing state of the valve by visually observing the position of the valve stem, which greatly improves the convenience and safety of operation.

The valve is connected to the pipeline through flange connection or other standard connection methods. It is easy to install and disassemble. It can be widely used in water supply and drainage, HVAC, petrochemical, electric power, metallurgy and other fields.

Technical parameters

Project	Parameter range
Nominal diameter	DN15 - DN1200 (customizable according to requirements)
Nominal pressure	PN1.0MPa - PN4.0MPa
Applicable temperature	-20℃ - 425℃ (depending on the material and sealing material)
Applicable medium	Water, steam, air, oil, gas, acid and alkali solution, etc.
Valve body / valve cover material	Ductile iron (QT400 - 18, QT450 - 10, QT500 - 7, etc.)
Gate material	Ductile iron (hard alloy can be welded on the surface)
Valve stem material	Alloy steel (2Cr13, 3Cr13, etc.)
Sealing type	Metal seal, soft seal
Connection method	Flange connection, welding connection, threaded connection
Drive mode	Manual, electric, pneumatic, hydraulic
Standard	Comply with GB (national standard), HG (chemical industry standard), ASME (American Society of Mechanical Engineers standard), ISO (international standard), etc.
