Fire Pipeline Clamp Type Soft Seal Butterfly Valve

The fire pipeline clamp type soft seal butterfly valve produced by Tanggu Shengshi Huagong is a fluid control valve widely used in industrial and civil pipeline systems, mainly used in water supply and drainage, HVAC, food and beverage, pharmaceutical and other industries where high sealing performance is required. The valve adopts a wafer-type installation method, and the connection is achieved by clamping the valve between two pipe flanges. It has the characteristics of compact structure, small space occupation, and convenient installation.

Send Inquiry

Product Description

The core soft sealing structure of our fire pipeline clamp type soft seal butterfly valve is to coat the edge of the butterfly plate with elastic sealing materials such as rubber and polytetrafluoroethylene (PTFE), and use the good flexibility and deformation ability of these materials to achieve zero leakage or extremely low leakage, effectively preventing medium leakage.

When it is working, the butterfly plate rotates 90° around the valve stem axis to realize the opening, closing and flow regulation functions of the valve. When the butterfly plate rotates to be parallel to the pipeline axis, the valve is fully open and the medium can pass smoothly; when the butterfly plate rotates to be perpendicular to the pipeline axis, the valve is closed, and the flow of the medium is cut off by the close fit of the soft sealing material.

The fire pipeline wafer-type soft-sealed butterfly valve manufactured by Shengshi Huagong has become a common equipment in the field of pipeline fluid control due to its reliable sealing performance, simple installation method and flexible operation characteristics.

Technical parameters:

Project	Parameter range
Nominal diameter	DN40 - DN1200
Nominal pressure	PN1.0MPa - PN16.0MPa
Applicable temperature	-20℃ - 200℃ (depending on the sealing material)
Applicable medium	Water, steam, air, oil, acid and alkali solution, etc.
Valve body material	Ductile iron, carbon steel, stainless steel, etc.
Butterfly plate material	Match with valve body, or use special alloy material
Sealing form	Soft seal (rubber, polytetrafluoroethylene, etc.)
Connection method	Wafer type
Driving method	Manual, electric, pneumatic
Standards	Comply with international and national standards such as ANSI, ISO, GB, etc.
